How Temperature Affects Butterfly Valve Seals
How Temperature Affects Butterfly Valve Seals
Temperature is the most critical factor affecting butterfly valve seal life. Choose the wrong seat material, and your valve will leak—whether from heat-induced compression set or cold-temperature embrittlement.
At Kinko, we engineer seats for every thermal environment. This guide helps you match seat material to your operating temperature.
Seat Material Temperature Limits
| Material | Temperature Range | Best For | Avoid |
|---|---|---|---|
| EPDM | -40°C to +120°C | Water, wastewater, HVAC | Oils, fuels, steam |
| NBR | -30°C to +100°C | Oils, diesel, fuels | Hot water, outdoor UV |
| Viton (FKM) | -20°C to +200°C | Acids, solvents, high heat | Low temperatures (<-20°C) |
| PTFE | -40°C to +230°C | Chemicals, steam, cryogenic | Low-pressure sealing (<3 bar) |
| Silicone | -60°C to +200°C | Extreme cold, food contact | Oils, high-pressure |
Key Temperature Effects
| Effect | Cause | Result |
|---|---|---|
| Compression set | Prolonged heat | Permanent deformation → leakage |
| Embrittlement | Extreme cold | Cracking → catastrophic failure |
| Hardening | Heat aging | High torque → actuator oversizing |
| Softening | Excessive heat | Reduced pressure rating |
Temperature Derating Factors (PN16 Valve)
| Temperature | EPDM | NBR | Viton | PTFE |
|---|---|---|---|---|
| -40°C to 0°C | 0.9x | 0.8x | 0.7x | 1.0x |
| 0°C to 80°C | 1.0x | 1.0x | 1.0x | 1.0x |
| 80°C to 120°C | 0.6x | Not allowed | 0.9x | 1.0x |
| 120°C to 200°C | Not allowed | Not allowed | 0.6x | 0.8x |
Quick Selection by Application
| Your Application | Recommended Seat |
|---|---|
| Hot / cold water (HVAC) | EPDM |
| Outdoor freeze-thaw | EPDM or Silicone |
| Diesel / oil transfer | NBR |
| High-temperature chemicals (150°C+) | Viton or PTFE |
| Steam / CIP sterilization | PTFE |
| Cryogenic (-196°C) | Special cryogenic seat |
| Food / potable water | EPDM (FDA grade) |
Signs of Temperature Failure
| Symptom | Problem |
|---|---|
| Leakage at low pressure | Compression set (too hot) |
| Cracks in seat | Too cold (embrittlement) |
| Stiff operation | Heat hardening |
| Melted / charred seat | Extreme overtemperature |
Conclusion
Match your seat material to your maximum and minimum operating temperatures—plus any excursion spikes. Kinko offers EPDM, NBR, Viton, PTFE, and Silicone seats across all valve series.
Need a seat recommendation? Contact Kinko with your media, temperature, and pressure for a free compatibility review.
